Cem Smd-100 Tweezers Type Multimeter

Product description

Smd-100 tweezer type multimeter can be easily used for measurements such as dc and ac voltage, resistance, capacitance, diode and continuity. It has a replaceable head for automatic scanning control of circuit fault. All inputs are protected according to en 610101-1 catiii 600v. General features automatic dc v or ac v selection, capacitance, resistance, continuity and diode selection

6000 digit lcd screen

Data hold / max / min record mode

Automatic shutdown

Wide range of capacitance

Technical specifications dc voltage: 600 v (±0. 8% accuracy)

Ac voltage: 600 v (±1. 0% accuracy)

Resistance: 60 mohm (±1. 0% accuracy)

Capacitance: 6 nf - 60 mf (±3. 5% accuracy)

Diode control: open voltage 2. 8vdc, test current 1ma

Continuity test: threshold value 35 ? Dimensions: 184 x 37 x 23 mm

weight: 76 g.
